Electric generator Mag-motoren 155SL, 13.6kVA

It is the only unit with fuel tank protection for optimal safety during operation.

The fuel tank cover is secure from loss – thread and ventilation function. Below is installed a fuel tank made of synthetic material from quality XPE material reducing the risk during refueling – volume approx. 12 litres.

Roll-over valve from the automotive industry for best ventilation and highest safety.

Three temperature warning sensors increase safety during operation.

Display in the latest LED technology for:

• operating hours
• voltage
• overvoltage or undervoltage
• SILENT button for reducing DAS RPM (option)
• power by phases
• overload of individual phase
• fuel level

Warning pictograms for:

• general warnings
• engine oil temperature
• oil pressure
• additional sound warning
• hint for instructions for use
• fuel temperature
• ambient temperature
• charging control
• fuses

The unit ensures simplicity and clarity with optimally arranged control elements, insulation monitoring with audible warning via horn according to DIN 14685-1.

It has service covers on both sides with magnetic closure and protective covers with warning pictograms.

Exhaust silencer made of alloyed steel operates extremely quietly. Fuel can be supplied from a canister via factory-installed three-point pipe and fuel kit for extended operation.

DIN exhaust system with spark arrester for your safety and possibility of connecting exhaust pipe.

Service cover with absorbent pad opens tool-free for best access during engine services

Easy access to fuses, which trip in case of thermal and electrical shocks.

The battery requires no maintenance. The battery has a switch for polarity change and automatic choke, which are factory-installed.

Handle grips are made of aluminium alloy for maximum stability. Central handle for easier lifting. Foldable and non-slip carrying handles that keep your hands warm in cold weather and allow ergonomically correct carrying position, air slot in the cover protects against overheating.

Tool bag is included as standard.

Frames, control panels, service and protective covers can be selected from the RAL colour palette (option).

You can access the catalogue in Slovenian language HERE.

Thermal Safety:

Firefighting power generators boast extremely high performance in small dimensions. The measurements are determined in DIN 14685-1. Consequently, high thermal loads, even within the installation in firefighting vehicles, are structurally addressed by the manufacturer. Mag Motorn power generators are designed for continuous operation, hence they exclusively use components that meet industrial requirements.

Electrical Safety:

DIN 14685-1 also specifies electrical requirements for power generators and the associated electrical safety. Power generators are serially produced with the safety measure of "Separation with potential equalization." Additionally, all power generators are equipped with insulation monitoring, which together with the previous measure forms an additional safety element.

Some technical terms in the field of power generators:

Low consumers:

These are consumers that draw the same current at startup as during operation (bulbs, hot plates, heating elements, ...)

Inductive consumers:

These are consumers that can draw up to 8 times the power at startup compared to the power stated for operation. These include various electric motors (single-phase or three-phase). This must be taken into account when selecting the power of the power generator.

Power:

The stated power (apparent power) in power generators is indicated in VA (voltamperes).

Power factor (cos phi):

This is obtained from the ratio of apparent and working power, usually used for three-phase current consumers. The acceptable value is 0.8. If the power of the power generator (indicated in VA) is multiplied by this factor, the working power of the generator is obtained (indicated in W - Watt).

Working power:

It is measured in Watts. The power stated by the manufacturer can be easily assumed when operating low consumers. For inductive consumers, the power factor must be considered.

Synchronous generators:

MAG Motorn exclusively uses synchronous generators suitable for all users. Generators can be cooled internally (IP 23 mode) or externally (IP 54 mode). Those used in outdoor environments must comply with the IP 54 mode.

Mag Motorn firefighting power generators meet the IP 54 requirements.
